Polystyrene Super Clear Antistatic Carrier Tape
Sinho’s this special PS (polystyrene) carrier tape is static dissipative and transparent. Its superior transparency performs in -pocket part inspection. It offers good strength and stability over time and temperature variations for a wide range of sizes and design, in accordance with EIA-481-D standards, ideals for packaging capacitor, inductor, crystal oscillator, EMC...
Both single-wind and level-wind are suitable for this material in corrugated paper and plastic reel flanges.
Details
| Superior Anti-static polystyrene material with high transparency | Ideal for packaging capacitor, inductor, crystal oscillator, EMC... | All SINHO carrier tape ismanufactured in accordance with current EIA 481 standards | ||
| Compatible with Sinho Antistatic Pressure Sensitive Cover Tapes and Sinho Heat Activated Adhesive Cover Tapes | Single-wind or level-wind in corrugated paper and plastic reel flanges for your choice | 100% in process pocket inspection |
Typical Properties
| Brands | SINHO | ||
| Material |
Polystyrene (PS) Clear Insulative |
||
| Overall Width |
8 mm, 12 mm, 16 mm, 24 mm, 32 mm, 44 mm, 56 mm, 72 mm, 88 mm, 104 mm |
||
| Application | Capacitor, Inductor, Crystal Oscillator, EMC... | ||
| Package | Single wind format on requested reels size Or Level wind format on 22” cardboard reel |
Physical Properties
PS Clear Insulative
|
Physical Properties |
Test method |
Unit |
Value |
|
Specific Gravity |
ASTM D-792 |
g/cm3 |
1.08 |
|
Mechanical Properties |
Test method |
Unit |
Value |
|
Tensile Strength @Yield |
ISO527 |
Kg/cm2 |
37.2 |
|
Tensile Strength @Break |
ISO527 |
Kg/cm2 |
35.4 |
|
Tensile Elongation @Break |
ISO527 |
% |
78 |
|
Electrical Properties |
Test method |
Unit |
Value |
|
Surface Resistance |
ASTM D-257 |
Ohm/sq |
109~11 |
|
Thermal Properties |
Test method |
Unit |
Value |
|
Heat distortion temperature |
ASTM D-648 |
℃ |
62 |
|
Molding shrinkage |
ASTM D-955 |
% |
0.004 |
|
Optical Properties |
Test method |
Unit |
Value |
|
Light Transmission |
ISO-13468-1 |
% |
91.3 |
|
Haze |
ISO14782 |
% |
17.8 |
Shelf Life and Storage
Product should be used within 1 year from the date of manufacture. Store in its original packaging in a climate-controlled environment where temperature ranges from 0~40℃, relative humidity <65%RHF. This product is protected from direct sunlight and moisture.
Camber
Meets current EIA-481 standard for camber that is not greater than 1mm in 250 millimeters length.
Cover Tape Compatibility
| Type |
Pressure Sensitive |
Heat Activated |
|||
| Material |
SHPT27 |
SHPT27D |
SHPTPSA329 |
SHHT32 |
SHHT32D |
| Polystyrene (PS)Supper Clear |
√ |
√ |
X |
√ |
√ |
Resources
| Physical Properties for Materials | Material Safety Data Sheet |
| Production Process | Safety Tested Reports |
